Description
- Specification Confirm to IS 5918-1984 Taper 1 in 50 Dimensions in mm.
- LH Helical Flutes for Rh Cutting shall be supplied unless otherwise specified.
| NOMINAL DIA. | CUTTING EDGE LENGTH | OVERALL LENGTH |
MORSE TAPER NO.
|
| 3mm | 58mm | 140mm | 1 |
| 4mm | 68mm | 150mm | 1 |
| 5mm | 73mm | 155mm | 1 |
| 6mm | 105mm | 187mm | 1 |
| 8mm | 145mm | 227mm | 1 |
| 10mm | 175mm | 257mm | 1 |
| 12mm | 210mm | 315mm | 2 |
| 16mm | 230mm | 335mm | 2 |
| 20mm | 250mm | 377mm | 3 |
| 25mm | 300mm | 427mm | 3 |
| 30mm | 320mm | 475mm | 4 |
| 40mm | 340mm | 495mm | 4 |
| 50mm | 360mm | 550mm | 5 |
